JOYMORE-7 machine roomless passenger elevator provides users with a safe, comfortable, energy-saving, and environmentally friendly product experience.
Level-A Energy Efficiency Certification.
Standby Energy Saving Technology.
Energy Regeneration System (Optional).
| NO. | Specification | 450 | 630 | 800 | 1050 | ||||||||||||||
| 1 | Capacity (kg) | 450 | 630 | 800 | 1050 | ||||||||||||||
| 2 | Speed (m/s) | 1 | 1.6 | 1.75 | 1 | 1.6 | 1.75 | 1 | 1.6 | 1.75 | 1 | 1.6 | 1.75 | ||||||
| 3 | Operation System | full collective selection operation | |||||||||||||||||
| 4 | Driving System | VVVF | |||||||||||||||||
| 5 | Door Operator System | VVVF | |||||||||||||||||
| 6 | Traction Machine | Permanent Magnet Synchronous Gearless type | |||||||||||||||||
| 7 | Control System | CTRL80 | |||||||||||||||||
| 8 | Wide Car1 | Car Dimension mm width*depth | - | 1100*1400 | 1350*1400 | 1400*1600 | |||||||||||||
| Shaft Size mm W*H | - | 1770*1800 | 1920*1800 | 2000*2000 | |||||||||||||||
| 9 | Deep Car1 | Car Dimension mm width*depth | - | - | - | 1100*2100 | |||||||||||||
| Shaft Size mm W*H | - | - | - | 1800*2500 | |||||||||||||||
| 10 | Deep Car2 | Car Dimension mm width*depth | 1000*1200 | 1100*1400 | 1350*1400 | 1100*2100 | |||||||||||||
| Shaft Size mm W*H | 1570*1600 | 1670*1800 | 1920*1800 | 1700*2500 | |||||||||||||||
