METIS-FL Firefighter Elevators

Name: METIS-FL
Brand: IFE ELEVATORS CO., LTD.

METIS-FL can be used as a firefighter elevator or a passenger elevator. It is installed in the fire-proof closed structure of the building to ensure the safe passage of users.

Specification Of METIS-FL Firefighter Elevators

NO.	Specification		800(10/P)			1050(14/P)				1350(18/P)				1600(21/P)
1	Capacity (kg)		800			1050				1350				1600
2	Speed (m/s)		1	1.75	2	1	1.75	2	2.5	1	1.75	2	2.5	1	1.75	2	2.5
3	Operation System		full collective selection operation
4	Driving System		VVVF
5	Door Operator System		VVVF
6	Traction Machine		Permanent Magnet Synchronous Gearless type
7	Control System		CTRL80
9	Parallel Elevators		2 units
10	Group Control Elevators		3-8 units
11	Wide Car	Car Dimension mm	1350x1400			1600x1500				1950x1500				1950x1750
		width*depth
13		Shaft Size mm	2000x2150			2200x2200				2600x2300				2600x2550
		W*H
14	Deep Car	Car Dimension mm	-			1100x2100				1200x2400				1400x2400
		width*depth
16		Shaft Size mm	-			2050x2550				2150x2850				2400x2850
		W*H
